19 Inch Rack Mount 0.1-500 MHz UHF Power Amplifier Solid State Psat 50 W RF Power Amplifier
Description
The 0.1-500 MHz UHF Power Amplifier is a versatile device designed to operate within the Ultra High Frequency (UHF) range, covering a wide frequency spectrum from 0.1 MHz to 500 MHz. Its key features include:
Frequency Coverage: This amplifier covers a broad frequency range, making it suitable for various UHF applications across different frequency bands.
Power Output: It offers adjustable power output, capable of delivering high power levels ranging up to several hundred watts, catering to diverse power requirements in different applications.
High Linearity and Low Distortion: Designed for high linearity and low distortion, it maintains signal accuracy and clarity during signal amplification processes.
Wideband Design: With a wideband design, it can handle multiple frequency signals simultaneously, making it suitable for applications requiring broad frequency coverage.
Stability and Reliability: Engineered for stability and reliability, it maintains consistent performance across different environmental conditions, ensuring high operational reliability.
Protection Features: It incorporates protection features such as overcurrent, overvoltage, and overtemperature protection, safeguarding the amplifier from external environmental factors and extending the device's lifespan.
Applications: It finds applications in wireless communication systems, RF testing equipment, radar systems, medical devices, broadcasting equipment, scientific research, and various other fields.
Connection Interfaces: Typically equipped with standard RF connectors such as N-type connectors or SMA connectors, it facilitates easy integration and connectivity with other RF equipment.
The 0.1-500 MHz UHF Power Amplifier is a comprehensive, stable, and widely applicable RF device suitable for amplifying and transmitting high-frequency signals across a range of applications.
Specification
Typical performance at +220VAC +25oC, and in a 50Ω system.
| RF / ELECTRICAL | ||||
| PARAMETER | MIN | TYP. | MAX | UNIT |
| Operating Frequency | 0.1 | 500 | MHz | |
| RF INPUT | 0 | dBm | ||
| PSat Power Output | 50 | 70 | W | |
| Gain | 47 | 49 | dB | |
| Power Gain Flatness | ±2.5 | dB | ||
| Input VSWR | 2 | — | ||
| Operating Voltage | 100 | 240 | V AC | |
Spurious Signals@Pout=47dBm | -60 | -50 | dBc | |
| Harmonic Signals@Pout=47dBm | -20 | -15 | dBc | |
| Gain Adjust Range | 31.5 | dB | ||
| Gain Adjust Step | 0.5 | dB | ||
| Power Dissipation | 800 | W | ||
| Input/output impedance | 50 | Ω | ||
| MECHANICAL | ||
| PARAMETER | VALUE | UNIT |
| Dimensions (L x D x H) | The standard 19-inch shelf is 5U high, 482*500*221 | mm |
| RF Connectors (Input / Output) | N-K / N-K (N female) | — |
| Control Connector | DB9:Power supply/power off control, gain control; Monitoring parameters include output power, temperature, supply voltage, and supply current | |
| Control Connector | RJ45:Remote control and monitoring can be realized through LAN | |
| Cooling | Built-in cooling system, forced air cooling | — |
| Weight | ≤25 | kg |
| ENVIRONMENTAL / PROTECTIONS | |||
| PARAMETER | MIN | MAX | UNIT |
| Operating Temp. (Housing Temp.) | 0 | +50 | °C |
| Humidity Range | 0-90 | % | |
| Protections | With over temperature protection, input over power protection, over voltage protection, over current protection, output mismatch protection | ||
| INPUT/OUTPUT panel Connector | |||
| AMPLIFIER CONNECTOR TYPE: | —— | ||
| TRIAD CABLE PART NUMBER: | —— | ||
| NUMBER | interface type | DESCRIPTION | |
| X1 | N-K | RF IN | |
| X2 | N-K | RF OUT | |
| X3 | LCD display | Human-computer interaction interface | |
| X4 | Switch | AC/220V/50Hz | |
| X5 | RJ45 | LAN | |
| X6 | DB9 | Control and monitoring interface | |
