High power density 15-500 MHz Past 53 dBm C Band RF High Frequency Power Amplifier
Description
The 15-500 MHz Psat 53 dBm RF Power Amplifier is designed to amplify signals within the frequency range of 15 MHz to 500 MHz, offering a Psat (saturated output power) of 53 dBm.
Frequency Range:
This power amplifier is suitable for amplifying signals across the frequency range of 15 MHz to 500 MHz, covering a wideband spectrum.
Psat and Power Output:
The amplifier provides a Psat (saturated output power) of 53 dBm, which corresponds to approximately 200 watts (W) of power. This high power output makes it suitable for applications requiring strong signal amplification.
Key Features:
Wideband Design: Capable of amplifying signals across a broad frequency spectrum from 15 MHz to 500 MHz, making it versatile for various applications.
High Psat: The 53 dBm Psat level provides ample power for signal transmission and processing in RF communication and testing systems.
High Efficiency: Some models exhibit high energy conversion efficiency, reducing energy consumption and heat generation.
Applications:
RF Testing and Measurement: Used in RF testing equipment and spectrum analyzers for signal amplification and analysis in laboratory and field settings.
Communication Systems: Suitable for signal amplification in RF communication systems operating within the 15-500 MHz frequency range.
Military and Aerospace Applications: Applied in military and aerospace systems for signal amplification and transmission.
Technical Characteristics:
High Linearity: Ensures accurate and stable signal amplification, crucial for maintaining signal integrity in various RF applications.
Multiple Interfaces and Control Methods: Supports various interfaces and control methods for ease of integration and use.
High Reliability: Designed for stability and reliability, suitable for continuous operation in demanding environments.
In summary, the 15-500 MHz Psat 53 dBm RF Power Amplifier is a versatile and high-power amplifier suitable for a wide range of RF applications, characterized by its wideband capability, high Psat, and reliability in signal amplification.
Specification
Typical performance at +44VDC +25oC, and in a 50Ω system.
| RF / ELECTRICAL | ||||
| PARAMETER | MIN | TYP. | MAX | UNIT |
| Operating Frequency | 15 | 500 | MHz | |
| RF INPUT | 0 | dBm | ||
| P-1dB Power Output | 53 | dBm | ||
| Power Gain | 53 | dB | ||
| Power Gain flatness | ±2 | |||
| Input VSWR | 2 | |||
| Spurious Signals | -60 | dBc | ||
| Harmonic Signals | -15 | -10 | dBc | |
| Operating Voltage | 44 | 48 | VDC | |
| Currents | 15 | A | ||
| In-Out impedance | 50 | Ω | ||
| MECHANICAL | ||
| PARAMETER | VALUE | UNIT |
| Dimensions (L x W x H) | 200*150*30 | mm |
| RF Connectors (Input / Output) | SMA- KFD/ N- KFD | — |
| DC / Control Connector | D-SUB 7W2 | — |
| Cooling | Baseplate Conduction – Optional Heatsink Available | — |
| Mounting | 3-4 Thru Hole | — |
| Weight | ≤2.5 | kg |
| ENVIRONMENTAL / PROTECTIONS | |||
| PARAMETER | MIN | MAX | UNIT |
| Operating Temp. (Housing Temp.) | -20 | +60 | °C |
| Humidity Range | 0-100 | % | |
| PA Baseplate Shutoff Temperature | + 85 | °C | |
| Connector Definition | ||
| AMPLIFIER CONNECTOR TYPE: | D-SUB 7W2 | |
| TRIAD CABLE PART NUMBER: | —— | |
| NUMBER | Definition | DESCRIPTION |
| 1 | VDD | 44V |
| 2 | GND | GND |
| 3 | Output power monitoring | Output detection analog voltage |
| 4 | PA Enable | TTL Hi= Enable, TTL Lo = Disable or No Connection |
